Foundation: Gabion Perimeter

3D model of terraced BioDome with gabion retaining walls and reciprocal roof frame — 3D model: terraced design with gabion retaining walls stepped into the hillside

Key Topics

Gabion cage sizing: 1m × 0.5m × 0.5m units (or custom to fit cut profile)
Stone fill: 10–20cm local granite or schist, hand-placed at corners and edges
Retaining wall integration: stepped courses following hillside cut
Front foundation: single gabion course at south face, anchors wattle wall frame
Pole anchor points: flat stone caps on gabion units, 40cm spacing
Drainage pipe routing: 100mm perforated HDPE at base of rear and side walls
